Description
Rockwell Offset Square Corner Shower Hinge in Chrome Finish for heavy tempered Glass Shower Doors
Classic Wall to Glass Shower door hinges fits 3/8″ to 1/2″ thick Tempered Glass
Square Corners OFFSET Full Backplate
Hinge Preset at Zero Degree
Finish: Polished Chrome
Material: Solid Brass
Opening Angle 90 degrees
Stainless Steel hardened Coil Springs
Self-centering when within 15 degrees of closed position
Reversible Pivot Pin
Also available Preset at 5 degree positive position
Using 2 hinges, with 3/8″ to 1/2″ glass the hinge will hold up to 80 lbs. with a maximum door width of 28″
Using 3 hinges, with 3/8″ to 1/2″ glass the hinge will hold up to 120 lbs. with a maximum door width of 32″
